Oil Recycling Machines



1) Burn the preheater first, use the flue to heat the distillation reactor, and pass the flue gas into the preheater.

2) Then, the waste oil preheated by the preheater is injected into the distillation reactor through the oil pump, and the heated waste oil is subject to distillation and pyrolysis.

3) Then enter the fractionating tower to fractionate the high-temperature oil and gas.

4) The upper air outlet is mainly composed of light oil and gas components, which are introduced into the shell and tube condenser for cooling. The middle air outlet is composed of oil and gas components, which are introduced into another shell and tube condenser. A port is set at the top of the preheating tank, which is introduced into the third shell and tube condenser.

5) Condensate the above three kinds of oil and gas respectively. Three condensers correspond to three oil tanks.

6) The non condensable gas passes through the safety water seal, also known as the flame arrester, and then the non condensable gas enters the furnace as fuel to heat the distilling furnace. Thus, the operation cost of distillation equipment can be saved.







No	Item	Content
1	Model	ODFJL-5	ODFJL-10	ODFJL-20	ODFJL-30	ODFJL-50
2	Raw material	crude oil/waste engine oil/heavy oil/tire oil/plastic oil/fuel oil		crude oil/waste engine oil/heavy oil/tire oil/plastic oil/fuel oil
3	Structure	horizontal
4	Capacity	5T/D	10T/D	20T/D	30T/D	50T/D
5	Oil yield	70~80%
6	Working pressure	Native pressure/vacuum
7	Power	35kw	40kw	50kw	75kw	90kw
8	Cooling system	water cooling
9	Heating mode	Directly heating
11	Installation	Have basis
12	Noise DB (A)	≤85
13	Area(M*M)	L10*W5	L15*W5	L30*W8	L50*W10	L80*W15
14	Woeking form	Semi Continuous		Continuous operation





Item	Function
Distilation reactor	The waste oil will be pumped into the reactor for refining.
Distillation column	Atmospheric Fractionator Ensure differrent Fraction come Out.
Condensing device	The oil gas will be cooled to liquid oil then flow to the oil storage tank
Vacuum pump	Ensure the distillation machine working under normal pressure.
Anti back fire device	Safety device , prevent the oil gas revert to the reactor.
Non condensable oil gas recycling system	The non condensed oil gas (Syngas ) will be recycled to heating system as fuel.
Color and smell removal system	the last step to remove bad smell and color to yellow diesel oil.
Dedust system	3 layers of ceramic packing dedusting to remove dust and acidity, non- pollution.
Safety devices	Auto releasing pressure device , alarm, safety valve , etc to ensure safety operating.





(1) The operation cost is low, and the non condensable gas generated in operation can be used as fuel.

(2) The equipment is easy to operate with low labor intensity. Only 1 worker/shift is required.

(3) Process and distill various waste oils, such as waste diesel oil, waste engine oil, various waste engine oil, waste plastic oil, tire oil, etc.

(4) The product oil is of high quality, and the cracked diesel oil can be used in industry, civil use, and even diesel engines.

(5) Good environmental protection effect. The equipment will not produce waste smoke, waste water, etc. during operation.

(6) High oil yield, up to 75% - 90% (based on the oil content of raw oil)



















Company Name	Zhengzhou Odifei Machinery Equipment Co., Ltd.
Covering Area	30000 Square Meters
Founded Year	2007
Certification	ISO, CE, Patents, SGS Report, ISO9000
Main Products	Pyrolysis Machine, waste tyre pyrolysis plant, waste plastic pyrolysis plant, tyre crusher, waste oil distillation plant, pyrolysis oil to diesel machine, waste engine oil refining machine, oil burner, diesel burner, heavy oil burner
Engineer Owned	4 R&D Engineers, 19 Technical People
International Market	15% Europe, 14% Southeast Asia, 33% Chinese Mainland, 5% America, 7% Africa, 8% Middle East, 3% East Asia, 11% South Asia, 4% Central Asia, 11% South Asia





1. What kind of raw materials can Oil Recycling Machines handle?

Odifei Oil Recycling Machines can process all kinds of waste motor oil, plastic oil, tire oil, waste diesel oil, waste industrial oil, etc.



2. What is the final product?

The main products are diesel, a small amount of gasoline and slag.



3. What is the oil yield?

Taking waste oil as an example, the oil yield is generally 70%-85%. According to the different oil content of the raw material, the oil yield is different.



4. What are the heating methods?

It can be heated with heat transfer oil, refined diesel, natural gas, coal, wood, electricity, etc.



5. Do you need other special chemicals in the production process?

With the refining technology we developed, only our catalysts are needed, and no acid-base washing is required.



6. What do customers need to prepare?

Customers only need to prepare the oil storage tank, waste oil tank, circulating water tank and power supply.



7. Is there any technical training?

We will arrange 1-2 technicians to go to the site to guide the installation. After the installation, we will provide technical training and on-site operation to the workers.



8. How long is the warranty period?

One year warranty, if you have any questions, we will reply within 24 hours!



9. How many workers are needed to operate this Oil Recycling Machines, and are specialized technicians required?

2 workers, no need for specialized technicians.



10. Can it be customized?

Yes, according to the material characteristics, Odifei will design the best solution for you.



11. Can I visit the Oil Recycling Machines in operation?

You are very welcome to visit China. We will take you to the customer site to see the entire operation process.
