Introduction of Medical Waste Shredder
Medical Waste Shredder is a kind of solid waste volume reduction machinery, environmental protection shredder equipment, which is used to shred medical waste products and materials, which is conducive to medical waste recycling and recycled plastics. For example: Uncontaminated infusion bottles (bags), syringes (needles removed), medicine bottles, and plastic packaging materials.
Why Medical Waste Must Be Shredded
| Objective | Explanation |
|---|---|
| Prevent reuse | Shredding makes items unrecognizable, eliminating needle/syringe reuse risk. |
| Volume reduction | Reduce volume by up to 70%, lowering transport and sterilization costs. |
| Enhanced sterilization | Smaller particles allow steam/autoclave to penetrate fully, killing pathogens. |
| Incineration readiness | Uniform shred size improves combustion efficiency in incinerators. |
| Protect workers | Contained shredding avoids manual breaking of sharp or infectious items. |
According to the WHO, inadequate treatment of medical waste contributes to millions of needle‑stick injuries annually. A proper shredder is not a luxury – it is a safety necessity.
Suitable Raw Materials
Medical Waste Shredder is a kind of machine used for fine grinding, commonly used in processing raw materials or leftover material, making it a smaller size. The typical example is to tear after the rubber or plastic scrap as raw material after melting and granulating, used to make plastic bottles, tire or, trash cans, and so on. Shredding machines used in the industries of plastic recycling are often used to break the large diameter PE plastic pipe material, bales of packing plastic film, big piles of plastic, and models.
Advantages of the machine
| Feature | Description |
|---|---|
| Hopper design | Low-profile/feed-through hopper to prevent operator hand access. Interlocked safety cover. |
| Cutting chamber material | Stainless steel 304 or 316L – resistant to corrosion from bodily fluids and chemicals. |
| Blade material | High‑alloy tool steel (e.g., Cr12MoV, D2) with hardness HRC 55‑60, anti‑corrosion coating. |
| Sealing system | Multi‑lip shaft seals + air purge to prevent liquid ingress into bearings. |
| Disinfection spray option | Integrated nozzles to inject disinfectant during shredding (optional). |
| Wash‑down capability | IP65-rated electrical panel, smooth surfaces, hinged covers for easy cleaning. |
| Emergency system | Large‑area e‑stop buttons, reverse function on jam (hydraulic models). |
| Containment | Negative pressure shroud option to capture aerosols – important for airborne pathogens. |
Technical Parameter
|
Model |
Power (kW) |
Rotor diameter(mm) |
Broken caliber(mm) |
Rotating speed(r/min) |
Mesh(mm) |
Weight(kg) |
|
180 |
2.2 |
150 |
180*200 |
100-150 |
9 |
100 |
|
230 |
4 |
215 |
230*215 |
130-200 |
9 |
340 |
|
300 |
5.5 |
235 |
300*220 |
220-300 |
9 |
480 |
|
400 |
7.5 |
260 |
405*270 |
400-600 |
9 |
660 |
|
500 |
11 |
290 |
520*300 |
460-650 |
9 |
870 |
|
600 |
15 |
310 |
610*340 |
600-800 |
9 |
1010 |
|
800 |
22 |
400 |
810*480 |
800-1000 |
9 |
2000 |
|
1000 |
45 |
500 |
1010*660 |
1000-130 |
9 |
3000 |
Application of Medical Waste Shredder
1. To tear into small pieces the unqualified product for recycling use.
2. to reduce the volume of raw materials to mix with other materials
3. Low organic material to make biofuels.
4. Reuse of some textile material for fiber, such as carpet.
In fact, a shredding machine is used to shred all kinds of plastic, rubber, tire, fiber, paper, wood, iron drum, waste electrical appliances, waste cable, industrial wastes, living garbage, and other solid or hollow materials.
Success case
The video of the machine
F&Q
Q: How do you prevent cross‑contamination during maintenance?
A: We provide a sanitation protocol (including recommended disinfectant spray) and quick‑open covers for safe cleaning.
Q: Is the Medical Waste shredder noisy? Can it be used inside a hospital?
A: Standard noise ~80‑85 dB. For hospital in‑house installation, we offer sound‑insulated enclosures reducing noise to <70 dB.
Q: Do you provide installation overseas?
A: Yes. We can send engineers to supervise installation and train your staff. Many customers also use our detailed video manuals.
Q: What is the warranty?
A: 12 months against manufacturing defects (excluding wear parts such as blades and screens). Lifetime technical support.
