Plastic Bottle Crusher Machine



With the continuous development of society, plastic products have been greatly applied. Together with synthetic rubber and synthetic fiber, it has formed three indispensable synthetic materials in today's daily life. Plastic products can be seen at any time in our daily life. At the same time, a large number of waste plastics also follow. As for plastic bags, it takes about 200 years to rot when they are buried underground, which will seriously pollute the soil; In the plastic recycling industry, plastic shredders deliver plastic products for shredding, which is conducive to plastic recycling, cracking and recycling of plastic particles to make plastic products again.





Model	JL-2600	JL-1900	JL-1500	JL-1200	JL-1000	JL-600
Spindle power (kw)	4-160*2	4-90*2	4-45*2	4-37*2	4-30*2	4-15*2
Spindle speed(r/min)	16-18	14-16	14-16	18-20	18-20	18-20
capacity(t/h)	25-60	10-25	8-18	6-15	5-10	2-5
Conveyor power(kw)	4-3kw	4-3kw	4-3kw
Number of cutter heads (pieces)	40	40	30	28	30	26
	Different materials, different number of knives and blades, can be customized
Cutter diameter(mm)	Φ720	Φ560	Φ530	Φ372	Φ360	Φ260
Crushing particle size(cm)	3-10	3-10	3-10	3-10	3-10	3-10
Silo size(mm)	2425*1400	2300*200	2000*2000	1400*1000	1200*1000	820*900
Dimensions(mm)	8200*4000*4300	8000*2500*2400	4000*1700*2400	3200*2000*1900	3000*2000*1900	2600*2000*1900
weight(t)	36	15	12	6	5	2.5





1. Meshing blade to break materials;

2. Select special blade with high hardness;

3. Strong structure and densely distributed ribbed plates ensure the strength of the box;

4. Automatic button control, safe and convenient;

5. The equipment is equipped with safety signs and relevant operation instructions to ensure safe use;

6. Provide conveyors according to user requirements.





1. The Plastic Bottle Crusher and power unit shall be firmly installed. If it is necessary to fix the Plastic Bottle Crusher for a long time, it shall be fixed on the cement foundation; If mobile operation of Plastic Bottle Crusher is required, the unit shall be installed on the base made of angle iron, and ensure that the pulley groove of power engine (diesel engine or motor) and Plastic Bottle Crusher are in the same rotation plane.
2. After the installation of the Plastic Bottle Crusher, check the fastening of the fasteners of each part, and tighten them if they are loose. At the same time, check whether the belt tightness is appropriate.

3. Before starting the Plastic Bottle Crusher, rotate the rotor by hand to check whether the tooth claw, hammer and rotor operate flexibly and reliably, whether there is collision in the crushing chamber, whether the rotation direction of the rotor is consistent with the direction indicated by the arrow, and whether the lubrication of the power machine and Plastic Bottle Crusher is good.

4. Do not replace the belt pulley casually, so as to prevent the explosion of the crushing chamber caused by too high rotating speed, or the working efficiency of the crusher affected by too low rotating speed.

5. After the Plastic Bottle Crusher is started, it shall be kept idle for 2 ~ 3min before feeding.

6. Pay attention to the operation of the Plastic Bottle Crusher at any time during work. First, the feeding shall be uniform to prevent blocking the crushing chamber; Secondly, don't work overload for a long time. In case of vibration, noise, high temperature of bearing and machine body, external spraying and other phenomena, stop the machine immediately for inspection, and continue to work after troubleshooting.







Zhengzhou Odifei Machinery Equipment Co.Ltd id founded in 2004, which is a specialized enterprise dedicated to R & D and production of the tire recycling plant, tire crusher, Plastic Bottle Crusher, tire cutter machine, rubber powder plant, tyre shredder machine, Plastic Bottle Crusher,plastic shredder, all kinds of crushing machines. our company by eputation first, service first, customer first is an objective and take integrity as life. All for customer's satisfaction efforts, all for the company's long term healthy development efforts. We solemnly promise that we will depelope us with good quality and credible after sale service! We sincerely welcome you to our company and give us suggestions and directions!!!





Q: When we establish one kind of shredder machine, can we use it to shred other materials?

A: Yes, you can. We will design the shredder machine for you as per your materials.



Q: How to choose a suitable shredder?

A: Please tell us your raw material and what capacity you need, we will recommend you the most suitable shredder.



Q: What About The Machine Installation?

A: For the Waste Tire Shredder / Rubber Crusher / Old Tire Recycling Machine installation, we will provide you the wire connection drawing and technical support, normally you can finish by yourself; but if you really need our technician, we will send technician to your working site as required.



Q: How About The Spare Parts?

A: We provide spare parts at cost price permanently and will give you the spare parts list when you purchase machine.



Q: Will you test the Plastic Bottle Crusher before delivery?

A: Yes, we will test every Plastic Bottle Crusher and production line before delivery and send you the working video. You also can come to us for inspection before delivery.





1. OEM Manufacturing welcome: Product, Package...
2. Design scheme, site layout
3. We will reply you for your inquiry in 24 hours.
4. After sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.





If you are interesting in Waste Plastic Bottle Crusher , please feel free contact us in 24 hours!

Welcome you visiting our factory!!!
