Powered Belt Conveyors



Belt conveyor is also called belt conveyor or belt conveyor, etc. It is an indispensable economical conveying equipment to form a rhythmic assembly line. Belt conveyors can be divided into heavy-duty belt conveyors according to their conveying capacity, such as mining belt conveyors; light-duty belt conveyors such as those used in electronic plastics, food light industry, chemical and pharmaceutical industries. The belt conveyor has the advantages of strong conveying capacity, long conveying distance, simple structure and easy maintenance, and can easily implement programmed control and automatic operation.

Belt conveyors are widely used in metallurgy, mining, coal, port, transportation, hydropower, chemical and other industries to load, ship, transfer or accumulate various bulk materials or articles. The belt conveyor has the advantages of large conveying capacity, simple structure, convenient maintenance, low cost and strong versatility.





1. For occasions where loading and unloading locations change frequently

2. The structure is simple, the maintenance is convenient, and the bottom is equipped with a universal wheel, which can move flexibly

3. Smooth operation and low noise

4. Long service life, compact structure and small footprint.









Sectional form	belt speed(m/s)	Band width B(mm)
		500	650	800	1000	1200	1400
		conveying capacity G(t/h)
Grooved belt	0.8	78	131
	1.0	97	169	278	435	655	891
	1.25	122	206	348	544	819	1115
	1.6	156	264	445	696	1048	1427
	2.0	191	323	546	853	1284	1748
	2.5	232	391	661	1033	1556	2118
	3.15			824	1233	1858	2528
	4.0					2202	2996
Flat belt	0.8	41	67	118
	1.0	52	88	147	230	345	469
	1.25	66	110	184	288	432	588
	1.6	84	142	236	368	553	756
	2.0	103	174	289	451	677	922
	2.5	125	211	350	546	821	111













Coal powder, crushed coal, soot, carbon black, ammonium bicarbonate, pyrite powder, ammonium chloride, copper concentrate powder, alumina powder, gypsum powder, limestone powder, soda powder, urea, activated carbon, sodium oxide, silicon Calcium acid, asbestos powder, synthetic resin, rubber powder, calcium carbide, pottery ten, synthetic fertilizer, powdered pesticide, calcium sulfate, thiamine, soda ash, powdered medicine, wheat, soybean, rice, sugar, starch, crushed charcoal, wood chips , sawdust, polyvinyl alcohol synthetic detergent, fly ash phosphate fertilizer, etc.





High temperature, toxic, flammable and explosive, highly abrasive, highly corrosive, highly adhesive, highly suspending, highly fluid, hard and brittle Materials that do not want to be broken.







1. The factors causing the deviation must be eliminated in time.

2. Adhere to the maintenance system to avoid man-machine accidents.

3. No-load start or stop, strictly abide by the operating procedures and sequences.

4. Keep records of equipment use and maintenance, and do a good job of handover work.





1. Check whether there is any abnormality in the joint part of the tape, such as cuts, cracks, etc., and damage caused by other reasons.

2. Whether the upper and lower layers of the tape are worn, and whether the sidewall is worn.

3. Check whether the rubber scraper of the cleaning device is severely worn and cannot be in close contact with the tape. If so, adjust or replace the rubber scraper.

4. Keep each idler rotating flexibly, and replace the non-rotating or damaged idler.

5. Refuel all kinds of bearings regularly.

6. Repair or replace other worn parts or components.

7. Repair or replace the tape.





Pre-Sale Service:

• Guide customers to choose the appropriate equipment model.
• Send engineering and technical personnel to the production site in time to plan the site for customers, design reasonable processes and solutions.
• We can design and manufacture products according to the special needs of customers to meet the different needs of investors



On Sale Service:

• Strict inspection of products before leaving the factory
• Ships according to contract



After-sale Service:

• The main warranty period of the equipment sold by our company is one year (except for the failure or damage caused by human factors, fuel factors or irresistible natural phenomena, and vulnerable parts are not covered by the warranty: fuel injectors, pump heads, photosensitive eyes, etc.).
• If the equipment failure is caused by human factors, the cost will be charged according to the factory price.
• After receiving the warranty notice, reply within 2 hours. 24 hours technical guidance to solve problems.







Zhengzhou Odifei Machinery Equipment Co., Ltd. has been focusing on conveying equipment for 17 years. Its main business is: spiral vibration vertical elevator, slat feeder, chain plate conveyor, slat conveyor, Powered Belt Conveyors, large angle Powered Belt Conveyors, screw conveyor Conveyor, chain bucket conveyor, TD belt bucket elevator, TH ring chain bucket elevator, NE bucket elevator, NSE bucket elevator and other full range of bucket elevators. TD75 Powered Belt Conveyors (or Powered Belt Conveyors), mobile conveyor, Powered Belt Conveyors with large inclination angle ribs; screw conveyor, shaftless screw conveyor; light, medium and heavy chain plate conveyor; chain bucket conveyor machine, SCD trough clinker conveyor; horizontal double shaft mixer; light, medium and heavy plate feeder; GZG motor vibration feeder; trommel screen, shaftless trommel screen;

In 2010, our company's R&D team entered the resource recycling industry, and successively developed domestic waste treatment scaly conveyors, domestic waste screening and sorting shaftless trommel screens, construction waste slat feeders, and electric arc furnace scaly scrap conveyors, which not only create It also creates objective social and environmental benefits, and is an indispensable part of the resource recycling industry chain.

Zhengzhou Odifei Machinery Equipment Co., Ltd. has continuously carried out technological innovation in the spirit of excellence, and has developed several practical new products. The product is advanced in design, fine in production, reliable in performance, has international advanced level, sells well at home and abroad, and aims to be the industry leader!





Q: Are you a factory or a trading company? When we build a Powered Belt Conveyors, can we use it to convey other materials?

A: We are a factory, established in 2007, specializing in the manufacture of spiral vibration vertical elevator, slat feeder, chain plate conveyor, slat conveyor, Belt conveyor, large angle belt conveyor, screw conveyor Conveyor, chain bucket conveyor, TD belt bucket elevator, and so on.

This belt conveyor can transport a variety of materials, such as powder, particle and block.



Q: How about spare parts?

A: We always provide spare parts at cost price and give you a list of spare parts when you buy the machine.



Q: Will you test the Powered Belt Conveyors before delivery?

A: Yes, we will test each machine and production line before delivery, and send the working video to you. You can also check with us before delivery.



Q: How long is the warranty?

A: one year. After one year, paid services are provided for life.



Q: What are the payment methods?

A: T/T, L/C are all available. Both USD and RMB are acceptable.



Q: Can the Powered Belt Conveyors be customized?

A: Yes, we are a manufacturer and accept customization.











1. Please provide material name, specific gravity, particle size, etc

2. Are there other characteristics: such as viscosity, temperature, corrosivity, etc?

3. Conveying length, horizontal conveying or inclined conveying?

4. Conveying capacity / hour



If you are interesting in Powered Belt Conveyors, please feel free contact us in 24 hours!

Welcome you visiting our factory!!!
