Continuous Plastic Recycling Machine

Continuous Plastic Recycling Machine

The Continuous Plastic Recycling Machine is an industrial continuous production equipment that breaks down high molecular polymers in waste plastics into low molecular chain oil and gas, and then cools them to obtain fuel oil, carbon black, and combustible gas.



Continuous Plastic Recycling Machine can pyrolyze many kinds of waste, such as:

Waste plastic: PP, PS, ABS…

Waste tyres, rubber;

Medical waste;

Oil sludge…



Raw material	Item	Fuel oil
Waste plastic	PE	85%-95%
	PP	80%-90%
	PS	80%-90%
	ABS	40%
	pure white plastic	60%-70%
	fishing net, safety net	45%-50%
	MAMEI	40%
	plastic brand	20%
	pulp	20%-30%
	daily life rubbish	30%-50%
	pure plastic cable	60%-80%
	pure purchase bag	50%

1. Pretreatment system: Waste plastics should be pretreated by dryers and crushers. The dryer can remove moisture. The crusher can break large pieces of plastic into smaller pieces. The pretreatment system can improve the efficiency of the entire continuous plastic waste recycling plant and extend the service life of the plastic oil refining equipment.

2. Feeding system.

3. Pyrolysis reactor

4. Discharge system: The system is automatic, pollution-free, and safe.

5. Precipitation device.

6. Condenser system.

7. Gas purification and recovery system, gas burner.

8. Environmental protection dust removal system

9. Intelligent control cabinet.
TIP:

The Continuous Plastic Recycling Machine can also be used to treat oil field sludge, waste tires, and waste rubber. The difference between the automatic waste tire pyrolysis machine and the continuous plastic pyrolysis machine is the pretreatment machine. The detailed process is the same as the waste plastic pyrolysis plant.

1. Continuous operation, stop once a month for routine maintenance.

2. The non-condensable gas can be used as fuel to heat the pyrolysis reactor, saving the operating cost.

3. PLC control, convenient management, and low labor intensity of workers.

4. Stable and safe, equipped with multiple protections such as alarm devices and safety devices.





• Exhaust gas: The exhaust gas is sealed by a safety water and then enters the burner for combustion. This can eliminate waste gas pollution and save a lot of fuel. Reduce operating costs. The combusted flue gas is discharged after being treated by the spray dust collector; it fully meets the emission standard.
• Wastewater: No wastewater is produced, and the water is used for circulating cooling. It is only consumed naturally every day.
• Waste residue: the solid residue in the reactor after the cracking of the plastic tire, the main component of which is carbon black. Carbon black can be sold directly or further processed by our professional carbon black processing machine.

Item	Details
Model	JZLY-20
Daily Capacity	20T
Working Method	Fully Continuous
Raw Materials	Waste Plastic, Tyre, Rubber, Oil Sludge
Reactor Size	D2600*L8000
Pattern	Horizontal & Rotary
Heating Materials	Charcoal, Wood, Fuel Oil, Natural Gas, LPG, etc.
Total Power	75kw/h
Floor Area (L*W*H)	45*25*10m
Operating Pressure	Normal Pressure
Cooling Method	Water Cooling
Life span	5-8 Years

Q: What else can the fully automatic pyrolysis equipment process besides the waste tires and plastic?

A: Usually, Odifei pyrolysis plant can process waste tires, rubber product wastes, plastic waste (excluding PVC and PET), and oily sludge.

Q: Can the pyrolysis oil from the automatic plastic recycling machine be used for driving cars?

A: No. Tire oil or plastic oil cannot be directly used in cars. It can be used directly and safely as fuel oil. After being refined by pyrolysis oil refining equipment, the diesel can be used in heavy machinery, agricultural machinery, and construction machinery.

Q: Can I know the required temperature in each phase of the pyrolysis process?

Oil gas generation: 160℃

Oil discharging finished: 280℃

Highest temperature acceptable for the reaction:350℃

Before the hot smoke enters the flue condenser: 200℃+

After the hot smoke enters the flue condenser: 100℃+

Final emission of the hot smoke: around 75℃

Q: How about the safety level of your Continuous Plastic Recycling Machine?

A: Odifei pyrolysis plant adopts many high-level  safety designs:

2. All the plants are configured with a fire protecting system; temperature and pressure exceeding alarm; automatic pressure-releasing system; extra-gas recycling system; automatic alarming system to ensure the safety for each step of the working process.

1. Design the installation drawings according to your site.

2. 1-year warranty, engineers available to serve at any time;

3. Periodical call visit, to make sure there are no problems with the equipment;

4. Design a specific maintenance program according to the different situations of your plant.

5. For each set of the machine, one technician will be sent to guide your installation, test the machine, and train your workers. Besides, we will provide one month's service for free.
