Biomass Burning Machines

Biomass Burning Machines

The Biomass Burning Machine is a biomass semi-gasification automatic control burner, a biomass pyrolysis burner that uses biomass wood pellets and other organic biomass as fuel. The machine is equipped with a double-fan water cooling device.

The Biomass Burning Machines have stable performance, small size, and stable heat supply. It is advocated by the environmental protection department and is deeply loved by market customers. It saves a large amount of energy for small and medium-sized enterprises, and also provides domestic environmental improvement. Reasonable solution. Biomass pellet burner, half ton Biomass Burning Machines, 0.5 ton Biomass Burning Machines can be equipped with boilers, coating lines, drying lines, and other equipment. If necessary, please contact us for details.

The overall work of Biomass Burning Machines is divided into three stages:

1. Ignition stage: first, the feeding dragon of the burner is powered on to carry out the pre-feeding action. After feeding, turn on the blower and the ignition rod to carry out the ignition action. The ignition time is about five minutes. Due to different materials and different ignition methods, the time length is different!

2. Feeding stage: after the ignition is successful, enter the fire feeding stage. The fire feeding is mainly composed of the feeding and air supply. The feeding speed can be changed by the frequency converter or adjusted by the time interval mode, and the air supply size can be adjusted by the frequency converter!

3. Heating stage: the heating stage is a large fire. After the temperature reaches the set value, it enters the small fire stage, which can effectively avoid the waste of fuel. When the temperature is low, the fire will burn again! Repeat the switch back and forth!



1. High complete combustion efficiency: Boiling semi-gasification combustion and tangential swirling air distribution design make the fuel and combustion complete, and the combustion efficiency can reach more than 90%.
2. Complete and stable combustion: no tempering or de-firing occurs when the equipment operates in a micro-pressure state;
3. Wide range of heat load adjustment: the heat load of the burner can be quickly adjusted within the range of 30%-120% of the rated load, and the starting block is responsive.
4. The pollution-free environmental protection benefits are obvious: the renewable biomass energy is used as the fuel to realize the sustainable utilization of energy. Using low-temperature staged combustion technology, the emission of nitrogen oxides, sulfur dioxide, and dust in flue gas is low, and it is an excellent substitute for coal stoves.
5. No discharge of tar, wastewater, and other wastes: using high-temperature gas direct combustion technology, tar is directly burned in the form of gas, which solves the technical problem of high tar content in biomass gasification and avoids the water quality issues caused by washing tar. Secondary pollution;
6. Simple operation and convenient maintenance: automatic feeding, wind removal, simple operation, small workload, and only one person on duty.
7. Low investment and low operating cost: The biomass combustion structure is reasonably designed, and the transformation cost is low when used in various boilers.

Model	0.5T	Dimensions	1800*1000*1300mm
Control cabinet	50*25*59mm	Bottom Blower	550w
Nozzle diameter	219mm	Secondary Oxygen Supply	550w
Nozzle center height	500mm	Silo Size	500*500*500mm
